Ultrasonic Flowmeter Study Overview

Flow Research has completed a new market study on the worldwide ultrasonic flowmeter market. The study was conducted by Flow Research. One goal of the study was to determine the size of the ultrasonic flowmeter market in 2007. In addition, forecasts through 2012 are included. The study is called The World Market for Ultrasonic Flowmeters, 3^rd Edition.

The study includes the following elements:

· Worldwide market size and market shares for ultrasonic flowmeters in 2007

· Market growth for all types of ultrasonic flowmeters through 2012

· Industries and applications where ultrasonic flowmeters are used, with market growth areas

· A product analysis for the main companies selling into the ultrasonic flowmeter market

· Strategies to manufacturers for selling into the ultrasonic flowmeter market

· Company profiles of the main suppliers of ultrasonic flowmeters.

One main goal of this study was to determine the size of the ultrasonic flowmeter market worldwide in 2007. This market continues to be one of the fastest growing flowmeter markets, which is driven in part by the expanding market for custody transfer of natural gas.

One important issue is the growth in the contrast between transit time and Doppler flowmeters. While Doppler flowmeters remain one of the best solutions for dirty liquids, transit time flowmeters have been showing faster growth in recent years. Much of the new product development is going into transit time meters. Transit time flowmeters are typically more accurate than Doppler meters, and multipath transit time meters are used for custody transfer of petroleum liquids. This study also looks at growth in the hybrid flowmeter market.

This study also examines the growing use of ultrasonic flowmeters for gas flow measurement. Custody transfer of natural gas is a fast growing market, especially with the increased popularity of natural gas as an energy source, and due to the rising price of both oil and natural gas. Custody transfer is one of a number of gas applications that are boosting sales of ultrasonic flowmeters.

Steam flow measurement is a new frontier for ultrasonic flowmeters. Currently, this market is dominated by differential pressure (DP) and vortex flowmeters. However, as the technology improves, this is becoming a growth area for ultrasonic flowmeters. Steam flow measurement is growing in importance as companies look to increase energy efficiency and cut energy costs. The high accuracy and reliability of ultrasonic meters make this an attractive option for some steam flow applications.

Background of Study

There are two main types of ultrasonic flowmeters: transit time and Doppler. A transit time ultrasonic flowmeter has both a sender and a receiver. It sends two ultrasonic signals across a pipe at an angle: one with the flow, and one against the flow. The meter then measures the “transit time” of each signal. When the ultrasonic signal travels with the flow, it travels faster than when it travels against the flow. The difference between the two transit times is proportional to flowrate.

Doppler flowmeters also send an ultrasonic signal across a pipe. Instead of tracking the time the signal takes to cross to the other side, a Doppler flowmeter relies on having the signal deflected by particles in the flowstream. These particles are traveling at the same speed as the flow. As the signal passes through the stream, its frequency shifts in proportion to the mean velocity of the fluid. A receiver detects the reflected signal and measures its frequency. The meter calculates flow by comparing the generated and detected frequencies. Doppler ultrasonic flowmeters are used with dirty liquids or slurries. They are not used to measure gas or steam flow.

Ultrasonic flowmeters were first introduced for industrial use in 1963 by Tokyo Keiki (which later became Tokimec) in Japan. Tokimec is located in Tokyo, Japan. In 1972, Controlotron (Hauppauge, New York) became the first U.S. manufacturer to market ultrasonic flowmeters in the United States. In the late 1970s and early 1980s, both Panametrics (Waltham, Massachusetts) and Ultraflux (Poissy Cedex, France) experimented with the use of ultrasonic flowmeters to measure gas flow. Initially, ultrasonic flowmeters were not well understood, and were sometimes misapplied. Many technological improvements have been made in the past 10 years, and the limitations of ultrasonic meters are better understood. Advances in transit time technology have broadened the types of liquids that transit time flowmeters can be used on. Many transit time meters today can handle liquids containing some impurities.

Rationale for Study

Since completing our first ultrasonic study in 2001, we have been following this market very closely. We published the 2^nd edition of this study in 2003. Many developments have been described in our quarterly report, the Market Barometer. Each issue of the Market Barometer includes an update on the ultrasonic flowmeter market. This new study builds on the knowledge we have gained over the years, but it is a completely new look at this market. For more information on the Market Barometer, go to www.worldflow.com.

Key Issues Addressed

This study addresses the key issues in the ultrasonic flowmeter market, including:

Growth in the ultrasonic transit time flowmeter market
Shipments of clamp-on, spoolpiece, and insertion meters
Comparison of portable vs. fixed ultrasonic flowmeters
The expanding use of ultrasonic flowmeters for custody transfer of natural gas
The emerging market for ultrasonic flowmeters in steam flow measurement
The market for Doppler and hybrid ultrasonic flowmeters
Mergers and acquisitions in the ultrasonic flowmeter market

Segmentation

The segmentation for this study is as follows.

Geographic Segmentation:

· North America

· Europe

· Middle East/Africa

· Japan

· China

· Asia without Japan/China

· Latin America

Average Selling Price of Ultrasonic Flowmeters by Region

North America
Europe
Middle East/Africa
Japan
China
Asia w/o Japan/China
Latin America

Ultrasonic Flowmeters by Technology Type

Text Box: What’s in this for my company?

· See the emerging applications and where the growth is
· Understand world and regional markets
· Get to know your real competition
· Learn what other suppliers manufacture, where, and for whom
· The best information creates the best decisions

There are four kinds of ultrasonic flowmeters:

Single and dual path transit time ultrasonic Flowmeters
Multipath transit time ultrasonic flowmeters

Doppler ultrasonic flowmeters
Hybrid ultrasonic flowmeters

Single and Dual Path Ultrasonic Flowmeters

Single and dual path ultrasonic flowmeters are segmented by the seven geographic regions (see above), with forecasts to 2012.

Multipath Ultrasonic Flowmeters

Multipath ultrasonic flowmeters are segmented by the seven geographic regions (see above), with forecasts to 2012.

Doppler Ultrasonic Flowmeters

Doppler ultrasonic flowmeters are segmented by the seven geographic regions (see above), with forecasts to 2012.

Hybrid Ultrasonic Flowmeters

Hybrid ultrasonic flowmeters are segmented by the seven geographic regions (see above), with forecasts to 2012.

Transit Time Ultrasonic Flowmeters

Transit time flowmeters are distinguished by path type as follows:

Clamp-On
Insertion

Ultrasonic Flowmeters by Mounting Type

This study distinguishes between mounting types as follows:

Clamp-on ultrasonic flowmeters
Spoolpiece ultrasonic flowmeters
Insertion ultrasonic flowmeters

Ultrasonic flowmeters are segmented by mounting type by geographic region. Forecasts to 2012 are included.

Clamp-On Flowmeters by Mounting Type

This study distinguishes between mounting types for clamp-on ultrasonic flowmeters as follows:

Portable clamp-on
Fixed clamp-on

Portable and fixed clamp-on ultrasonic flowmeters are segmented by geographic region, with forecasts to 2012.

Clamp-On and Insertion Ultrasonic Flowmeters by Fluid Type

· Text Box: What makes Flow Research so special?

· Our only focus is flowmeters and process instrumentation.
· We research the big three: manufacturing, distribution, and application.
· Our end-user surveys and perspectives are unique to the industry.
· Our Worldflow Monitoring Service keeps you up-to-date between studies.
· We only succeed when you do. Liquid

· Gas

· Steam

Clamp-on and insertion ultrasonic flowmeters are distinguished by fluid type by geographic region. Forecasts to 2012 by fluid type are included.

Spoolpiece Ultrasonic Flowmeters by Fluid Type

Spoolpiece ultrasonic flowmeters are segmented in this study according to fluid type:

· Liquid

· Gas

· Steam

Spoolpiece ultrasonic flowmeters are distinguished by fluid type by geographic region. Forecasts to 2012 by fluid type are included.

Transit Time Ultrasonic Flowmeters by Signal Type

· Diametral

· Chordal

· Hybrid

Transit time ultrasonic flowmeters are segmented by signal type by geographic region. Forecasts to 2012 are included.

This study distinguishes line sizes for ultrasonic flowmeters as follows:

Clamp-On Ultrasonic Flowmeters

< 2 inch
2 - 4 inches
> 4 – 8 inches
> 8 – 12 inches
> 12 – 20 inches
> 20 inches

Insertion Ultrasonic Flowmeters

< 4 inches
4 – 8 inches
> 8 – 12 inches
> 12 – 20 inches
> 20 inches

Spoolpiece Ultrasonic Flowmeters

< 2 inch
2 - 4 inches
> 4 – 8 inches
> 8 – 12 inches
> 12 – 20 inches
> 20 inches

Clamp-on, insertion, and spoolpiece ultrasonic flowmeters are segmented by the seven geographic regions. Forecasts to 2012 are included by line size for all three types of ultrasonic flowmeters.

Ultrasonic Flowmeters by Intelligence Level:

Ultrasonic flowmeters are segmented in this study according to type:

· Smart

· Conventional

Ultrasonic Flowmeters by Communication Protocol

Ultrasonic flowmeters are segmented by the following protocols:

· HART

· Foundation Fieldbus

· Profibus

· Modbus

· Proprietary Digital

· Other

Shipments of Transit Time Ultrasonic Flowmeters by Number of Paths

· Single Path

· Dual Path

· Three Path

· Four Path

· Five Path

· Six + Paths

Transit time ultrasonic flowmeters are segmented by six paths by geographic region. Forecasts to 2012 are included.

Shipments of Ultrasonic Flowmeters by Application

· Custody Transfer-Natural Gas

· Custody-Transfer- Liquids

· Check Metering

· Process Measurement

· Flare/Stack Gas

· District Heating

· Other

Ultrasonic flowmeters are segmented by application by geographic region. Forecasts to 2012 are included.

Clamp-On and Insertion Ultrasonic Flowmeters by Industry

Ultrasonic flowmeters are used mainly in the process industries. The following industries are included in this study:

· Oil & Gas Production, Transportation, and Distribution

· Refining

· Chemical

· Pharmaceutical

· Food & Beverage

· Pulp & Paper

· Metals & Mining

· Power

· Water & Wastewater

· Other

Clamp-on and insertion ultrasonic flowmeters are segmented by industry by each of the seven geographic regions. Forecasts worldwide and by region are included to 2012.

Spoolpiece Ultrasonic Flowmeters by Industry

· Oil & Gas Production, Transportation, and Distribution

· Refining

· Chemical

· Pharmaceutical

· Food & Beverage

· Pulp & Paper

· Metals & Mining

· Power

· Water & Wastewater

· Other

Ultrasonic flowmeters by Sales Channels

The Ultrasonic flowmeter market is segmented according to the following sales channels:

Direct Sales
Independent Representatives
Distributors
E-Business

Ultrasonic flowmeters are segmented by sales channels by geographic region. Forecasts to 2012 are included.

Ultrasonic flowmeters by Customer Type

The Ultrasonic flowmeter market is segmented according to the following customer types:

End-Users
OEMs
Systems Integrators
Engineers/Consultants

Ultrasonic flowmeters are segmented by customer type by geographic region. Forecasts to 2012 are included.

Publication Date

The study was published in January 2008.
